Leaf chains are steel chains using a simple link plate and pin construction. The chain number refers to the pitch and the lacing of the links. The chains have particular features like for example high tensile strength per section area, that enables the design of smaller machines. There are A- and B- kind chains in this particular series and both the BL6 and AL6 Series have the same pitch as RS60. Lastly, these chains cannot be driven using sprockets.
In roller chains, the link plates maintain a higher fatigue resistance due to the compressive tension of press fits, yet the leaf chain only contains two outer press fit plates. On the leaf chain, the most acceptable tension is low and the tensile strength is high. While handling leaf chains it is vital to consult the manufacturer's instruction manual to be able to ensure the safety factor is outlined and use safety guards all the time. It is a great idea to carry out extreme caution and utilize extra safety guards in applications where the consequences of chain failure are severe.
Utilizing a lot more plates in the lacing results in the higher tensile strength. In view of the fact that this does not improve the maximum acceptable tension directly, the number of plates utilized could be restricted. The chains require regular lubrication as the pins link directly on the plates, producing a really high bearing pressure. Using a SAE 30 or 40 machine oil is frequently suggested for most applications. If the chain is cycled more than one thousand times daily or if the chain speed is more than 30m for every minute, it will wear very rapidly, even with constant lubrication. So, in either of these situations using RS Roller Chains will be much more suitable.
The AL-type of chains should just be used under particular situations like when wear is not a huge problem, when there are no shock loads, the number of cycles does not go over a hundred day after day. The BL-type will be better suited under various situations.
If a chain utilizing a lower safety factor is selected then the stress load in components will become higher. If chains are used with corrosive elements, then they can become fatigued and break rather easily. Performing frequent maintenance is important if operating under these types of conditions.
